The TP30 Engine Powered Pump has been designed for reliability, durability and ease of use.

The 4 Stroke Over Head Valve designed engine is built to industrial specifications making it economical and reliable.

The engine comes with a low oil cut out system which will prevent the engine from seizing should the pump tip over or run low on engine oil.

The pumps come with a starter pack which includes 1 litre of oil, spare spark plug, spare air filter, spark plug spanner and screwdriver.

 Construction and Features

170F ENGINE SPECS

• 212cc – 7 hp
• Recoil starting system
• 600ml oil capacity
• Single cylinder, four stroke OHV
• 6l fuel tank capacity
• 5h continuous running time

• Trash Pump
• Inlet/Outlet: 3 inch
• Hmax: 25m
• Qmax: 61m3/h
• Comes with: Hose connections and inlet strainer
• Self-priming
• Suction lift: 7m

• Cast iron cylinder liner
• Ball bearing supported crankshaft
• Dual element air cleaner
• Mechanical decompressor
• Industrial governor system
• Electronic coil
• Low oil cut out system
• Heavy duty roll frame with rubber feet
• Mechanical Seal: Carbon/Ceramic
• O-rings: Nitrile

The pump is shown on the graph as the blue line

 .
